Click above view the General Arrangement plan



Click above view the brocure in Australian and Chinese















First Ferry IX, X, XI

These three 28 meter passenger ferries were designed by Sea Speed Design (CMCS) in Australia and were built by Wang Tak shipyards in China and Hong Kong. They are operated by New World First Ferry in Hong Kong as high speed ferries to the outlying islands. With a full

load, cruise speed is 25 knots and are very succussful examples of econimical ferry transport. Carrying 230 passengers in Air Conditioned comfort, the vessels are powered by twin MTU 12V1000 engines at 1080 hp each.

Features include low-wash hulls with high-slip hull forms giving great fuel economy. These hulls were tank tested and refined giving even better performance.

http://www.dreamstime.com/glassy-green-square-video-camera-icon-image5803991 Click here to see Video 1  http://www.dreamstime.com/glassy-green-square-video-camera-icon-image5803991 Click here to see Video 2

Click here to see more photos and find out more about the construction process.

Click here to see the Work Boat World article on First Ferry IX.

Click Here to see Fast Ferry article.

Length Overall :
Beam :
Depth :
Draft :
Type :
Class :

Capacity :
Hull Material :
Superstructure Material :
Speed :
Main Engine :
Gearboxes :
Propellers :
Generator :
Year Built :

28.23 metres
8.50 metres
2.50 metres
1.00 metres
Aluminium Passenger Catamaran
LRS SSC Passenger Catamaran HSC G2 /HKMD.
235 PAX
Aluminium Alloy
Aluminium Alloy
25 Knots ( @85% MCR )
2 x MTU12V2000M70@788kW
2 x ZF2500A
2 x 5-bladed FPP
2 x Perkins 4TGM @62kW
2002
